Name: Automatic Blister Packing Machine Cold Formable Alu Alu Packaging Machinery
Brand: WENZHOU HUALE MACHINERY CO.,LTD
SKU: DPP-250E
Price: 22,500.00 USD
Availability: InStock

Home Products Pharmaceutical Blister Packaging Machines

Automatic Blister Packing Machine Cold Formable Alu Alu Packaging Machinery

Product Details:

Place of Origin:	CHINA
Brand Name:	HUALE MACHINERY
Certification:	CE ISO9001
Model Number:	DPP-250E

Payment & Shipping Terms:

Minimum Order Quantity:	1Set
Price:	$15000-$30000
Packaging Details:	WOODEN BOX.
Delivery Time:	35 working days after received your payment.
Supply Ability:	10 Sets per month

Contact Now

Detailed Product Description

Product Name:	Automatic Blister Packing Machine	Pulling:	Step Motor Driving Or Servo Motor Driving
Punch Pin:	PTFE（High Temperature Resistant, Non Stick Coating）	Detection System:	Mechanical Detection Or Visual Inspection
Used:	Alu-PVC Blister And Alu-Alu Blister	Weight:	1200kg
Highlight:	Blister Packaging Machine Pharmaceutical Industry , food vacuum packing machine

Automatic Blister Packing Machine Cold Formable Alu Alu Packaging Machinery

This machine is suitable for pack capsules and tablets which request high packaging standard to protect its quality and extend expiration date. This machine combined with two function:aluminum foil cold forming blister and PVC thermal forming blister. The two functions transform by changing modules.

Quick Detail:

MODEL:	DPP-250E
Blanking frequency (Cutting/min):	15-30
Sheet's quantity of one blanking (sheets):	1-4
Capacity (sheets/hour):	12,000
Adjustable scope of feed travel: (mm)	10-160
Max Forming area and depth (mm)	270×120×25
Capacity of air compressor(m3/min):	≥0.36
Power supply:	380V AC, 50 Hz, Three Phase
Total Power	8Kw
Wrapper specification (mm): PVC Film Blister foil Alu Alu Foil	Max.270× (0.15-0.5) Max.270× (0.02-0.035) Max. 270*(0.11-0.25)

Description:

1. Travel scope can be adjusted.

2. Alu Alu Blister Packaging is available for this machine.

3. Mould is located by locating groove which makes it easy to change mould. The machine heats the PVC through conduction and forms it through pressing and frothing.

4. The material is fed automatically. The mould and feeder can be designed as user’s requirements.

5. Speed is shifted by step-less transducer. Adopt the interface of human-machine and PLC programmable controller, it can synchronize accurately.

6. Adopt the equipment of trace pressing, batch number printing and scarp-collecting.

7. Stepping motor Pulling Material more accuracy and easy adjusting

8. The heating moulds will automatically separate when the machine stops, which contributes to protect the material between them and extend the machine’s life.

Machine sketch
