Snack Stretch Vacuum Food Packaging Machine Semi - Automatic

Snack Stretch Vacuum Food Packaging Machine Semi - Automatic

  • Snack Stretch Vacuum Food Packaging Machine Semi - Automatic
  • Snack Stretch Vacuum Food Packaging Machine Semi - Automatic
  • Snack Stretch Vacuum Food Packaging Machine Semi - Automatic
  • Snack Stretch Vacuum Food Packaging Machine Semi - Automatic
  • Snack Stretch Vacuum Food Packaging Machine Semi - Automatic
Snack Stretch Vacuum Food Packaging Machine Semi - Automatic
Product Details:
Place of Origin: China
Brand Name: HUALE MACHINERY
Certification: ISO9001
Model Number: DDLZ-320
Payment & Shipping Terms:
Minimum Order Quantity: 1Set
Price: discussion
Packaging Details: packed with PE film and fixed in export wooden box
Delivery Time: with in 45 working days upon receipt the machine deposit
Payment Terms: T/T or L/C
Supply Ability: 20 Set per year
Contact Now
Detailed Product Description
Machien Name: Food Stretch Vacuum Packing Machine Packing Ways: Body Fitted Plastic Plastic/ Paper Plastic/ Hard Plastic Package
Application: Various Foods, Meat, Seafood, Fruits And Vegetables
Highlight:

packaging and sealing machine

,

filling and sealing machine



Snack Stretch Vacuum Food Packaging Machine Semi - Automatic





Applications:



This packing machine is a high precision equipment in our company. It is suitable for all kinds of film thickness and hard film stretch forming.





Descriptions

  • The machine come with edge wast recycling system,maintain environmental hygiene.
  • Adopt advanced cross cutting, slitting system, convenient replacement operation.
  • Use combination molds which equipped with cooling system, easy to replace so that more than one usage in one machine.
  • Panasonic servo motor, touch screen, PLC and other control system make the machine easy to operate and adjust.
  • Photoelectric tracking function, can choose the color cover film or film for packing.Reduce cost and improve product quality.
  • Nitrogen can be filled on the basis of pumping vacuum also other packaging can do according to customer’s product packaging requirement.



TECHNICAL PARAMETER



Model

DDLZ-520

DDLZ-420

DDLZ-320

Upper Film Width

492mm

392mm

292mm

Lower Film Width

522mm

422mm

322mm

Vacuum Degree

≦200pa

≦200pa

≦200pa

Compressed air

≧0.6Mpa

≧0.6Mpa

≧0.6Mpa

Cooling water

≧0.15Mpa

≧0.15Mpa

≧0.15Mpa

Power

380V 50HZ

380V 50HZ

380V 50HZ

Weight

2100kg

1700kg

1300kg

Dimension

6200×1400×1900mm

6200×1400×1900mm

6200×1400×1900mm





WARRANTY

  1. Technical Support(24 hours on line whatsapp, skype, MSN, mobile).
  2. Loading inform(loading port, destination port, shipping date, CBM, weight, etc.)
  3. Video for debugging after sent products.
  4. Pre-maintance.
  5. Quality guarantee for 1 year. Within warranty period, we provide spare parts for replacement free if not man-factor.
  6. Welcome send us samples to test on our machine and we will take video for you to confirm.
  7. Welcome visit our factory for checking machine and offer training course for your workers.



MANUFACTURING GOOD QUALITY MACHINE & PROVIDING EXCELLENT AFTER SERVICE!
