Plastic Thermoforming Wrapping Machine Automatic Alu PVC Blister Packing Machine

Plastic Thermoforming Wrapping Machine Automatic Alu PVC Blister Packing Machine

  • Plastic Thermoforming Wrapping Machine Automatic Alu PVC Blister Packing Machine
  • Plastic Thermoforming Wrapping Machine Automatic Alu PVC Blister Packing Machine
Plastic Thermoforming Wrapping Machine Automatic Alu PVC Blister Packing Machine
Product Details:
Place of Origin: CHINA
Brand Name: HUALE MACHINERY
Certification: CE
Model Number: DPP-140A
Payment & Shipping Terms:
Minimum Order Quantity: 1Set
Price: $9000-$11000/set
Packaging Details: packed with plastic film then fixed in export wooded box
Delivery Time: within 40 working days after received your payment
Supply Ability: 10 Sets per month
Contact Now
Detailed Product Description
Product Name: Blister Packing Machine Pulling: Step Motor Driving
Material Consist: SS304/316 Control: PLC Control
Detection System: Mechanical Detection Or Visual Inspection Plate Correspondence: PRC System
Used: Pill Or Capsule Or Tablet Or Food Etc.
Highlight:

PVC Blister Packing Machine

,

Blister Packaging Machinery



Plastic Thermoforming Wrapping Machine Automatic Alu PVC Blister Packing Machine





Applications


Blister Machine DPP-140A is good for producing small batches and high quality blister packs in:
Pharmaceutical Research and Development laboratories, Clinical trials, Stability studies, Package development, Marketing, samples, Pharmaceutical production and packaging departments.





Specifications



Model

140A

Machine Body

Stainless Steel 304

Blanking frequency(times/min)

15-45

Adjustable pulling length

30-120mm

Blister Plate Size

Design According To Customers’ Requirements

Max Forming area and depth(mm)

140*110*15 (20 need Private custom)

Air compressor

(Don't provide)

0.6-0.8Mpa  ≥0.4m3/min

Mould cooling

(Recycle water or circulating water consumption)

40-80 L/h

Power supply

(Three phase)

380V/220V 50HZ 5.5KW

(According to the customer need to

select the voltage)

Wrapper specification(mm)

PVC

160*(0.15-0.6)*(Φ400)

Aluminum foil

160*(0.02-0.035)*(Φ400)

Overall Dimension(L*W*H)(including foundation)

2400*650*1450

Dimension of Each Part

1300*650*1250front)

1050*650*1450(back)

Weight

About 800kg




FEATURES

  • Full function PLC & MMI
  • automatic vibration disco brush feeder
  • Separate embossing and trace-pressing stations
  • Recipe program through MMI
  • Full stainless steel 304body
  • Shorter changeover time
  • Forming station: Flat plate type
  • Sealing station: Flat plate type
  • Utmost simplicity in operation & maintenance
  • GMP Compliance




OVERALL SKETCH


Plastic Thermoforming Wrapping Machine Automatic Alu PVC Blister Packing Machine 0Plastic Thermoforming Wrapping Machine Automatic Alu PVC Blister Packing Machine 1



WARRANTY

  1. Technical Support(24 hours on line email,skype, wechat, whatsapp).
  2. Loading inform(loading port, destination port, shipping date, CBM, weight, etc.)
  3. Video for debugging after sent products.
  4. Pre-maintance.
  5. Quality guarantee for 1 year. Within warranty period, we provide spare parts for replacement free if not man-factor.
  6. Welcome send us samples to test on our machine and we will take video for you to confirm.
  7. Welcome visit our factory for checking machine and offer training course for your workers.
